Price range: 35,000 ฿ through 55,000 ฿
คุณสมบัติเด่นของสินค้า
การบริการ
| Working Table Size | 300 × 200 mm |
|---|---|
| Axis Options | 3 Axis, 4 Axis, 5 Axis |
| Travel (X/Y/Z) | 300 mm / 200 mm / 100 mm |
| Max Working Stroke | XYZ = 300 × 200 × 100 mm |
| Spindle Motor Power | 500 W (0.5 kW) |
| Spindle Speed | 0 – 12,000 rpm |
| Drive System | XYZ 1204 Ball Screw |
| Repeatability (XYZ) | 0.01 mm |
| Positioning Accuracy | 0.01 mm |
| Interface | USB Port |
| Power Supply | 220V / 110V |
| Machine Weight | 33 kg |
| Table Material | Aluminum alloy T-table + Water tank |
| Rack Material | 15 mm PVC + corner brace |
| Suitable Materials | Up to ≤100 mm thickness |
| Warranty | 1-year machine warranty (6 months for core components) |
